Section 1. Aircraft Overview Eclipse 5OO Systems Manual
Copyright © — Eclipse Aviation Corporation
4 Version 2.0 April 2007
1.3 Seating Arrangements
Standard seating is a five place configuration; however an optional six seat is
available. Seats may be removed from the aircraft to provide additional space.
Removal of seats is accomplished by pulling four release wires at the base of each
seat. Doing so releases the seat base from the tracks; it can then be slid forward and
removed.
For ease of entry and stowing baggage passenger seats have a lever on the aisle
facing side that allows the seats to fold forward. To return the seats to the upright
position, push the seatback up and aft until it locks in position.
Figure 4. Standard Five Seat Configuration
Figure 5. Six Seat Configuration
