Eclipse 500 User Manual

Section 9. Climate Control Eclipse 5OO Systems Manual
Copyright © — Eclipse Aviation Corporation
196 Version 2.0 April 2007
Table 28. Flow Control Valve Manual Shutoff Operation *
AIR SOURCE Switch Position Flow Control Valve Position
NORM
Both flow control valves are in automatic control
mode.
L
Left flow control valves is in automatic control mode.
Right flow control valve closed.
R
Left flow control valve closed.
Right flow control valve is in automatic control
mode.
OFF
Both flow control valves closed.
* Using AIR SOURCE switch.
When the AIR SOURCE switch is set to an “on” position (NORM, L, or R), the flow
control valves will not open if any of the following conditions exist:

Bleed air temperature is too high

Engine is starting
When the AIR SOURCE selector is placed in the OFF, L or R position, a L (R) AIR
SOURCE SELECTOR status message appears, indicating that one or both of the
bleed air sources is off.
If a flow control valve fails, a L (R) BLEED VALVE FAIL advisory message appears.

Eclipse 500 Specifications

General

Manufacturer	Eclipse Aerospace
Model	Eclipse 500
Type	Very Light Jet
Engines	2 × Pratt & Whitney Canada PW610F turbofans
Thrust per engine	900 lbf (4.0 kN)
Wingspan	37.9 ft (11.6 m)
Height	11.0 ft (3.4 m)
Avionics	Avio NG
First Flight	August 26, 2002
Maximum Speed	430 mph
Range	1, 125 nautical miles
Service Ceiling	41, 000 ft (12, 500 m)
Crew	1 or 2
Max Takeoff Weight	6, 000 pounds
Seating Capacity	4-6
Length	33 feet 6 inches
Empty Weight	3, 550 pounds
Payload	Varies with configuration and fuel load
