Ecotech HiVol 3000

HiVol 3000 User manual 1.7 Introduction
3
1.2 Specifications
1.2.1 Flow control
Volumetric flow-rate range:
 45-96m
3
/h
Flow accuracy:
 better than ±1m
3
/h
Flow repeatability
 1.0% of reading
Vacuum Capability:
 140 mBar (max)
1.2.2 Temperature/Pressure Measurement
Temperature Range
 0-45°C
Temperature accuracy:
 ±1°C
Barometric Range:
 600-900 mmHg (Torr)
 (800-1200 hPa)
Baro. Pressure accuracy:
 ±4 mm Hg (Torr)
1.2.3 Power supply
Voltage, frequency:
 240VAC±10%, 50/60Hz, single phase 1500VA MAX
 110VAC ±10%, 50/60Hz, single phase 1500VA MAX
Power consumption :
 1500VA max
 Depending on filter loading and flow rate
Power connector:
 10A weatherproof inlet
 (Australian pin configuration)
 (weatherproof coupling supplied)
 IP56 with coupling fitted
Note: A qualified electrical contractor must fit
the wireable socket to an appropriate supply
cord. Refer to Section 2.4.1 for details
