HiVol 3000 User manual 1.7 Operation
41
Wind OK?
Is wind condition (sector/speed) active?
Power OK?
Is power supply voltage in range?
* - if Wind Sp. Parameter is zero, wind direction displays zero data
Note: “Tot. Vol.”, “Cor.Volume” and “RunTime”
parameters may be reset to zero by Clearing
Accumulated data in the Setup Logger Setup
Menu.
3.5.2 Setup Menu
The Setup Menu contains a number of sub-menu items and some direct entry
parameters, where the user can program various parameters.
Times menu
See section 3.5.2.1
Wind menu
See section 3.5.2.2
Trigger menu
See section 3.5.2.3
Logger menu
See section 3.5.2.4
Clock menu
See section 3.5.2.5
Flow Alarm menu
See section 3.5.2.6
Major fault
See section Error! Reference source not found.
Flow
Set sampler flow-rate, m
3
/hour
Ref.Temp.
Set STP standard temperature, °C
Ref. BP
STP standard pressure, mmHg
Size Select
Sets SSI flow rate limits active
Protection
Sets restrictions on changes to certain parameters
