Operation HiVol 3000 User manual 1.7
30
3.2 General operational information
Figure 13. HiVol 3000 control panel
The HiVol 3000 is microprocessor based and features internal data logging of flow
and meteorological parameters.
The internal data logger stores time based records at user-selectable intervals. The
data includes Date and Time, flow-rate (volumetric), sample volume (uncorrected and
corrected to Standard Temperature and Pressure conditions), average temperature,
pressure, wind speed and wind direction or rainfall information. Values stored in the
sampler may be downloaded via the RS-232C Serial port.
The HiVol 3000 includes an input connector for wind speed and direction. These
inputs are averaged and stored in the unit, and may be used as triggers for conditional
sampling (eg. sampling when the wind direction is within a specified range). The
HiVol also incorporates a time clock and programmable timer enabling multiple time-
based sampling programs to be configured.
4 line LCD display
6 function keypad
