3 - 8 AG45134 Rev. 3
plate registration. Always handle and position the plate gently and
carefully. Thin plates are especially susceptible to dings and dents.
Figure 3-6 External View of the System
Loading Edge-registered plates
Step 1. Face the front of the recorder.
FRONT VIEW
POWER SWITCH
CONTROL PANEL
PINCH ROLLER BAR
TRANSPORT
REAR VIEW
INPUT TRAY
FAN FILTER
PEDESTAL
PIN BAR
