Hardware Installation
2.6.2 Internal
Audio Connectors
The CD-in (J5) and
A
UX-in (J6) connector
s are use
d to receive
audio from a CD-ROM drive
,
TV tuner or MPEG card.
14
Right audio
channel
Left audio
channel
Ground
Ground
W
AUX-in
14
Right audio
channel
Left audio
channel
Ground
Ground
CD-in
