Cadence II Fetal Monitor Service Manual
－ 20 －
Definitions for J1 2005S30P
Definitions for J2 LCM
PIN No. Function Description
PIN1 VO
PIN2 AA0
PIN3 WR
PIN4 RD
PIN5 AD0
PIN6 AD1
PIN7 AD2
PIN8 AD3
PIN9 AD4
PIN10 AD5
PIN11 AD6
PIN12 AD7
PIN13 LCDCS
PIN14 LCDRST
PIN15 LCDVEE
PIN16 Earth: 0V
PIN17 PD0
PIN18 PD1
PIN19 PD2
PIN20 PD3
PIN21 PD4
PIN22 PD5
PIN23 PD6
PIN24 PD7
PIN25 /ACK
PIN26 PE
PIN27 /STB
PIN28 /ERR
PIN29 BUSY
PIN30 VCC
PIN No. Function Description
PIN1 Earth: 0V
PIN2 VCC
PIN3 VO
PIN4 AA0
PIN5 WR
PIN6 RD
PIN7 AD0
PIN8 AD1
PIN9 AD2
PIN10 AD3
PIN11 AD4
PIN12 AD5
PIN13 AD6
PIN14 AD7
PIN15 LCDCS
PIN16 LCDRST
PIN17 LCDVEE
PIN18
Earth:
0
V
