Cadence II Fetal Monitor Service Manual
－ 30 －
Table 2-7 Indicator description
2.1.5 Recorder
If the transducers and connectors are connected well, press to print. The date,
time, FHR type, TOCO type, paper speed, bed No., and the offset of FHR2/DECG trend,
etc. will be recorded at the beginning of the paper. The offset of FHR2/DECG pattern is
–20bpm means that FHR2/DECG pattern is 20bpm lower than its actual position, so
Indicator Status of Indicator
Meaning
Green and twinkle Fetal heart signal quality is optimal
Orange and twinkle Fetal heart signal quality is unacceptable
FHR Indicator
(including
channel 1 and
channel 2)
Off Ultrasound transducer is off
Green and twinkle DECG signal quality is optimal
Orange and twinkle DECG signal quality is unacceptable
DECG Indicator
Off DECG cable connector is off
Green
TOCO pressure is at the range from 0 to 100
Orange
TOCO pressure equals to 0 or is over 100
TOCO Indicator
Off TOCO transducer is off
Green
Intrauterine pressure is at the range from 0 to
100
Orange
Intrauterine pressure equals to 0 or is over
100
IUP Indicator
Off Intrauterine pressure connector is off
Green Enable printing
Green and twinkle No paper or recorder error
Print Indicator
Off Disable printing
Green Enable audio alarm
Red and twinkle Alarm
Alarm Indicator
Off Disable audio alarm
Green Power on
POWER
Indicator
Off Power off
Green
Charging
Charge Indicator
Off
No battery or electric charge is full
