20bpm should be added when calculating the numerical value of FHR2/DECG. After
printing the information mentioned above, “FHR1”, “FHR2”/“DECG” will be recorded
above the relevant trends. In the process of later printing, the recorder will print system
time once every 10 minutes and “FHR1”, “FHR2”/“DECG” once every 8 minutes (see
Figure 2-8).
If pressing key, the symbol of TOCO zero is printed. If the key is
pressed, the marking symbol of “↓”will be printed at the trace. If alarm occurs, the
symbol “ ” will be printed at the trace.
Please set all parameters well before printing, and do not try to change the setup in the
process of printing.
Note: The printing speed can not be changed in the process of printing.
Figure 2-8 An example of printing pattern
: Indicates the alarm status information of monitoring.
: Indicates the fetal movement.
↓ : Indicates the event mark.
: Indicates the information of auto zero.
Note: When paper is used up, the recorder will stop printing and the data of waiting
printing will be kept in the memory. After feeding paper again, you can press the
key to continue. The current printing data will lose when ultrasound
transducer or DECG cable connector falls off, or power off.
