Cadence II Fetal Monitor Service Manual
－ 29 －
Press this key to return to the main interface quickly under the status of menu.
(8)
Function: ① Press the key to select fetal heart audio channel, the default fetal heart
audio channel is US1. ② When the cursor is moved to the menu item to be executed/
revised, this item will be encircled by a pane. Press this key to execute relevant function
or press this key, and this item will display reversed, then press the / key to
revise the relevant content, and press this key to confirm.
(9)
Function: Increase the fetal heart audio volume of the channel selected; Press ①②
the key under the monitoring mode, then press this key to play back backward; ③
Press this key to move the cursor downward among the menu items after entering the
menu interafce. Adjust the values of items in menu.④
(10)
Function: Decrease the fetal heart audio volume of the ch① annel selected; Press ②
the key under the monitoring mode, then press this key to play back forward; ③
Press this key to move the cursor upward among the menu items after entering the
menu interafce. Adjust the values of items in menu.④
2.1.4 Indicator
Figure 2-6 Display area diagram
Parameter Frame
Trend Frame
Information Frame
To Next Page
