Chapter 13
| Power over Ethernet Commands
– 401 –
show power inline
time-range
This command displays the time-range and current status for specific ports or for all
ports.
Syntax
show power inline time-range
time-range-name [interface]
time-range-name - Name of the time range. (Range: 1-32 characters)
interface
ethernet
unit - Unit identifier. (Range: 1)
port - Port number. (Range: 1-8/24)
Command Mode
Privileged Exec
Example
Console#show power inline time-range ethernet 1/5
Interface Time Range Name Status
--------- ---------------- --------
Eth 1/ 5 r&d Inactive
Console#
Related Commands
power inline (397)
Table 80: show power inline status - display description
Field Description
Compatible Mode Shows if the switch detects and provides power to powered devices that were
designed prior to the IEEE 802.3af PoE standard (see power inline compatible)
Maximum
Allocation Mode
The maximum power allocation mode based on the global configuration
command power mainpower maximum allocation
Interface The PoE port
Admin The administrative power mode set on the port (see power inline)
Time Range The time range during which power is supplied (see time-range)
Oper The current operating power status (displays on or off). Note that if power is
turned off due to an overload, administative status will still display enabled.
Class Shows the maximum power allocation class if defined by the global
configuration command power mainpower maximum allocation. Class
information is shown only when Oper = On.
Max Power The maximum power allocated to this port (see power inline
maximum allocation)
Used Power The current power consumption on the port in milliwatts
Priority The port’s power priority setting (see power inline priority)
