Chapter 5
| Port Connections
How to Connect to SFP/SFP+ Fiber Optic Ports
– 39 –
1000BASE-T Cable Requirements
All Category 5 UTP cables that are used for a 100BASE-TX connection should also
work for 1000BASE-T, providing that all four wire pairs are connected. However, it is
recommended that for all critical connections, or any new cable installations,
Category 5e (enhanced Category 5) or Category 6 cable should be used. The
Category 5e and 6 specifications include test parameters that are only
recommendations for Category 5. Therefore, the first step in preparing existing
Category 5 cabling for running 1000BASE-T is a simple test of the cable installation
to be sure that it complies with the IEEE 802.3-2008 standards.
Connection Procedure To make a connection to the switch’s management port follow the procedure
described in “How to Connect to the Management Port” on page 49.
How to Connect to SFP/SFP+ Fiber Optic Ports
The switch provides 48 slots for SFP/SFP+ fiber-optic transceivers. Note that all 10G
SFP+ fiber optic ports operate at 10 Gbps full duplex. All 1000 Mbps SFP fiber optic
ports operate at 1 Gbps full duplex.
3 Bi-directional Pair B Plus (BI_DB+) Bi-directional Pair A Plus (BI_DA+)
4 Bi-directional Pair C Plus (BI_DC+) Bi-directional Pair D Plus (BI_DD+)
5 Bi-directional Pair C Minus (BI_DC-) Bi-directional Pair D Minus (BI_DD-)
6 Bi-directional Pair B Minus (BI_DB-) Bi-directional Pair A Minus (BI_DA-)
7 Bi-directional Pair D Plus (BI_DD+) Bi-directional Pair C Plus (BI_DC+)
8 Bi-directional Pair D Minus (BI_DD-) Bi-directional Pair C Minus (BI_DC-)
Table 5: 1000BASE-T MDI and MDI-X Port Pinouts (Continued)
Pin MDI Signal Name MDI-X Signal Name
Table 6: Maximum 10 Gigabit Ethernet Fiber Cable Lengths
Fiber Size Fiber Bandwidth Maximum Cable Length Connector
10GBASE-SR
62.5/125 micron multimode 160 MHz/km 2-26 m (7-85 ft.) LC
62.5/125 micron multimode 200 MHz/km 2-33 m (7-108 ft.) LC
50/125 micron multimode 400 MHz/km 2-66 m (7-216 ft.) LC
50/125 micron multimode 500 MHz/km 2-82 m (7-269 ft.) LC
50/125 micron multimode 2000 MHz/km 2-300 m (7-984 ft.) LC
10GBASE-LR
9/125 micron single-mode N/A 10 km (6.2 miles) LC
