– 9 –
Tables
Table 1: Key Technical Specifications 13
Table 2: Fan Tray Specifications 28
Table 3: AC Power Supply Module Specifications 30
Table 4: Maximum Twisted-Pair Copper Cable Lengths 37
Table 5: 1000BASE-T MDI and MDI-X Port Pinouts 38
Table 6: Maximum 10 Gigabit Ethernet Fiber Cable Lengths 39
Table 7: Maximum Gigabit Ethernet Fiber Cable Lengths 40
Table 8: Maximum 40 Gigabit Ethernet Fiber Cable Lengths 42
Table 9: Maximum 10GBASE-CR 10 Gigabit Ethernet Cable Lengths 44
Table 10: Maximum 40GBASE-CR4 40 Gigabit Ethernet Cable Lengths 44
Table 11: System Status LEDs 48
Table 12: RJ-45 Management Port Status LEDs 49
Table 13: Console Cable Wiring 51
Table 14: Troubleshooting Chart 54
