210E / 210ECL / 2010 / 2010ECL / 2018ECL SERIES SIGNAL MONITOR
OPERATIONS MANUAL
Eberle Design Inc. Page 16
To enable a channel pair for FYAc operation, place the Option DIP Switch labeled “FYA x-
y” (where “x-y” is 1-9, 3-10, 5-11, or 7-12) in the On position. When the “FYA x-y” switch is
in the Off position, channel x will operate in standard fashion. If all four “FYA x-y” DIP
switches are in the Off position, channels 9, 10, 11, and 12 all operate in standard fashion
and the remapping of Channel 9 and 10 Green and Yellow described above is not done.
See Section 4.4.8.1.
Because of the remapping of the inputs to channels 9, 10, 11, and 12 Green, the
functionality of the Yellow and Red inputs of channels 9, 10, 11, and 12 is not provided for
when FYAc operation is enabled. The SSM switches for these four channels should be
placed in the Off position.
This Permissive Programming (Conflict Matrix) assignment example assumes standard
channel assignments for an eight phase quad intersection. The Permissive programming
for channels 9, 10, 11, and 12 (solid Green Arrow) are unchanged from conventional
programming for a protected left turn phase, with the addition of the jumpers for the
associated FYAc channels. The Permissive programming for FYAc channels 1, 3, 5, and 7
(solid Yellow and flashing Yellow Arrow) must be set with similar programming to the
associated through phase. For example:
Primary Channel
Permissive With
1
2, 5, 6, 11
2
5, 6, 11
3
4, 7, 8, 12
4
7, 8, 12
5
6, 9
6
9
7
8, 10
8
10
9
11
10
12
11
--
12
--
NOTE: This example is for illustrative purposes ONLY. Permissive Programming for
an application depends on actual intersection geometry, cabinet wiring, and
Controller programming.
- WARNING -
IF THE PERMISSIVE FLASHING YELLOW ARROW AND PROTECTED GREEN
ARROW CHANNEL ASSIGNMENTS ARE SWAPPED SUCH THAT THE FYA INPUT
IS MONITORED ON CHANNELS 1,3,5, AND 7:
1) The Flashrate Fault function monitors the enabled flashing Yellow Arrow input of
channels 9,10,11, and 12. The Flashrate Fault function must be disabled. See
Section 4.5.7.
2) Exit Flash into Start-up in all Yellow signals is not permitted.
3) Time of Day flash in all Yellow signals is not permitted.
