EDI 210E - Page 24

210E / 210ECL / 2010 / 2010ECL / 2018ECL SERIES SIGNAL MONITOR
OPERATIONS MANUAL
Eberle Design Inc. Page 19
>> RMS-Engine Firmware Type 01, RMS-Engine Firmware V2.3
>> ECcom Version 3.6.2
>> Downloaded at 10:21:27 AM Friday, September 22, 2006
>> Number of events = 2
AC Event #1 at:
2:41:30 PM Tuesday, January 02, 1996
Restore AC & WDT
AC Line Voltage = 119 Vrms @60 Hz
AC Event #2 at:
2:41:25 PM Tuesday, January 02, 1996
Brownout AC & WDT
AC Line Voltage = 85 Vrms @60 Hz
4) Manual Reset (MR) Event Log
>> Monitor Reset Event Log
>> Monitor ID #73
>> EDI Model 2010ECL, Firmware Type 01, Firmware V5.0, Comm V3.6
>> RMS-Engine Firmware Type 01, RMS-Engine Firmware V2.3
>> ECcom Version 3.6.2
>> Downloaded at 10:23:31 AM Friday, September 22, 2006
>> Number of events = 2
Monitor Reset Event #1 at:
9:50:08 PM Friday, January 26, 1996
Monitor Reset Event #2 at:
2:33:39 PM Wednesday, January 24, 1996
5) Configuration (CF) Event Log
>> Configuration Log
>> Monitor ID #73
>> EDI Model 2010ECL, Firmware Type 01, Firmware V5.0, Comm V3.6
>> RMS-Engine Firmware Type 01, RMS-Engine Firmware V2.3
>> ECcom Version 3.6.2
>> Downloaded at 10:13:48 AM Friday, September 22, 2006
>> Number of events = 10
>> (A '*>' symbol indicates that parameter has changed)
------------------------------------------------------------------------
CONFIGURATION CHANGE #1 at:
10:13:27 AM Friday, September 22, 2006
Permissive Programming:
Ch 1 with: 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Ch 2 with: 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Ch 3 with: 4 5 6 7 8 9 10 11 12 13 14 15 16
Ch 4 with: 5 6 7 8 9 10 11 12 13 14 15 16
Ch 5 with: 6 7 8 9 10 11 12 13 14 15 16
Ch 6 with: 7 8 9 10 11 12 13 14 15 16
Ch 7 with: 8 9 10 11 12 13 14 15 16
Ch 8 with: 9 10 11 12 13 14 15 16
Ch 9 with: 10 11 12 13 14 15 16
Ch 10 with: 11 12 13 14 15 16
Ch 11 with: 12 13 14 15 16
Ch 12 with: 13 14 15 16
Ch 13 with: 14 15 16
Ch 14 with: 15 16
Ch 15 with: 16
Red Fail Enable (X=Enable):
Ch: 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
X X X X X X X X X X X X X X X X
Dual Indication Enables (X=Enable):
Green-Yellow Dual Enable:
Ch: 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
. X . X X . X X . . . . . . . .
Yellow-Red Dual Enable:
Ch: 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
. X . X X . X X . . . . . . . .
Green-Red Dual Enable:
Ch: 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
. X . X X . X X . . . . . . . .
Yellow Disable (X=Disable):
Ch: 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
. . . . . . . . . . . . . . . .
Unit Data:
Red Fail Fault Timing = 1200-1500 ms
Recurrent Pulse = ENABLED
Watchdog Timing = 1.5 seconds
GY Enable = DISABLED
*> SF#1 Polarity = NORMAL
*> LEDguard Thresholds = ENABLED
