Specify the IP address to assign the device.
Click to assign the IP address to the device.
IV-6-1-2. LAN Port Settings
The “LAN Port” page allows you to configure the settings for your AP
Controllers wired LAN (Ethernet) ports.
Identifies LAN port 1 or 2.
Enable/disable specified LAN port.
Select a speed & duplex type for specified LAN
port, or use the “Auto” value. LAN ports can
operate up to 1000Mbps and full-duplex
enables simultaneous data packets
transfer/receive.
Enable/disable flow control. Flow control can
pause new session request until current data
processing is complete, in order to avoid
device overloads under heavy traffic.
Enable/disable 802.3az. 802.3az is an Energy
Efficient Ethernet feature which disables
unused interfaces to reduce power usage.
