Installing the Reference Unit
PhaseTrakker AP30
6
The portable Reference Unit (below) receives AC power supplied through the AC
power cord only, and does not provide an Alarm switch.
Network Antenna
(Threaded Connector)
GPS Antenna
AC Power Cord
Connection
(Bayonet Connector)
Naming the Reference Unit (Optional)
By default, the Reference Unit is set with system frequency of 60 Hz and the
name “RUnnnnnnnnnnn”, where nnnnnnnnnnn is the Electronic Serial Number (ESN)
of the unit’s wireless networking device. The PhaseTrakker Utility is needed only
to change the Reference Unit system frequency (50 or 60 Hz) or enter a custom-
ized name (alphanumeric, up to 16 characters).
