PhaseTrakker AP30 Using the Field Unit
25
Unreferenced Readings
If the Field Unit cannot connect to either of the configured Reference Units, the
following screen is displayed with an error sound.
The AP30 can take readings even when it cannot connect to a Reference Unit.
Unreferenced readings are recorded as UNRESOLVED, and will be automatically
resolved when a Reference Unit comes back online. Press OK or simply continue
taking readings with the Hotstick Unit.
Message indicates
Unreferenced Mode
Phase Shift setting will be
stored with reading
Phase Labels are
not displayed in
Unreferenced
Mode
Note: In Unreferenced Mode, the AP30 cannot detect changes in phase
from the Hotstick Unit signal. You must remove the Hotstick Unit from
energized sources to interrupt the signal between records.
