EDM Avistar PhaseTrakker AP30 - Understanding ACB Sequence; Customizing Phase Angles

PhaseTrakker AP30 AP30 Phasing Conventions
51
ACB Sequence
In the ACB sequence, the order of the voltage waveforms through time is A, C,
and B. For the AP30, the first waveform is always A and its zero crossing rising is
always 0°.
Three-Phase Voltage Waveforms
Zero Crossing RisingZero Crossing Rising
Voltage
V
A
V
B
V
C
+
-
ACB Sequence
0°
+360° Range
±180° Range
V
C
lags V
A
by 120° V
C
leads V
A
by 240°
V
B
leads V
A
by 120° V
B
lags V
A
by 240°
Phase Angles
The AP30 allows customization of phase sequence, labels, and angles to suit the
preferences of the user. The phase angles are 120° apart, and can be labeled
according to preference.
V
C
, V
B
+120°, -120° (+240°)
V
A
0°
120°
120°
120°
V
B
, V
C
-120° (+240°), +120°
