Specifications
PhaseTrakker AP30
52
Specifications
System
• System Accuracy: ±5°
• Repeatability: ±2°
Reference Unit
• Power source: 120 V (108 V – 132 V), 60 Hz or 50 Hz
• Demand draw: 0.1 Amps
• Data storage: 1 month of records to resolve phase identifications
• Operating temperature: -20° to 150° F
• Size
o Portable: 14.2” L x 11.4 “ W x 6.5” H
o Rack mount: 14.0” L x 17.0” W x 3.5” H
• Weight
o Portable: 8.7 lbs
o Rack mount: 8.0 lbs
Field Unit
• Operating temperature: -32° to 150° F
• Size: 19.2” L x 15.2” W x 7.3” H
• Weight: 25.2 lbs (including Hotstick Unit and accessories)
• Battery: 12 V rechargeable
• Battery life: 6 hours continuous use
• Battery charge times
o AC: 6 hours
o Auto: 7 hours
Hotstick Unit
• Universal hotstick attachment
• ¼ x 20 threaded hole for tip attachments
• Test lead attachment on sensor
• Voltage Range: 120 V to 500 kV, 60 Hz and 50 Hz
• Transmitter: 433 MHz FM, Range 50’
• Battery: 9 V
• Battery Life
o Active: 18 hours or about 500 readings at 2 minutes each
o Shelf: 1 year
• Size: 11.3” L x 3” W x 3” H (sensor: 4.9” L x 2.7” W x 1.3” H)
• Weight: 1.4 lb (sensor: 0.3 lb)
