Introduction
A352-02-840 Issue A
1Introduction
1.1 Scope and definitions
This manual provides assembly instructions for ES/EH combinations when the EH mechanical booster pump, ES single
stage rotary pump and ES/EH combination kit are purchased separately and not as a pre-built system.
Depending on the ES/EH variant the completed combination system will either be direct mounted or frame mounted.
Please refer to combination instruction manual A53202880, pump instruction manual A35201880 and EH booster
instruction manual A30151880 for full details.
Full ES/EH installation and commissioning instructions are given in ES/EH Combination instruction manual A53202880.
The part numbers and mounting type are given in Table 1 below:
2Safety
The units used throughout this manual conform to the SI international system of units of measurement.
3 Unpack and Inspect
Remove all packaging and check that all items listed have been received. If not, notify the supplier as soon as
possible.
Ensure base runners are fitted to the combination system. Failure to fit base runners may make
the combination system unstable.
Only lift the combination system as defined in the ES/EH combination instruction manual
A53202880.
Table 1 - ES/EH combination mounts
Description Mount Item Number
ES100 - EH250 Combination Kit Direct A52010100
ES100 - EH500 Combination Kit Direct A52010120
ES200/300 - EH500 Combination Kit Direct A52010130
ES200/300 - EH1200 Combination Kit Direct A52010140
ES300 - EH2600/4200 Combination Kit Frame A52010150
ES630 - EH1200 Combination Kit Direct A52010160
ES630 - EH2600/4200 Combination Kit Frame A52010170
Ensure the pumps are disconnected from the electrical supply to avoid accidental operation.
