Edwards ES Series User Manual

© Edwards Limited 2014. All rights reserved. Page 3
Edwards and the Edwards logo are trademarks of Edwards Limited.
Unpack and Inspect
A352-02-840 Issue A
Table 4 - ES200/ES300 - EH500 combination kit (A520-10-130)
Qty Part Number Description Check ()
2 A20501052 Frame/base runner 
1 C10007155 Adaptor ISO63-ISO63 bolted (including bolts) 
2 B27158170 ISO63 trapped O-ring 
4 C10007151 ISO63-ISO100 half claw for tapped holes 
4 218181452 10 x 25 bolt 
4 218981311 M10 washer 
4 218983511 M10 s.coil washer 
1 A35202880 EH Mechanical Booster/ES Single Stage Rotary Pump
Combination Pumping Systems instruction manual

1 A35202840 ES EH Combination Kits instruction manual 
Table 5 - ES200/ES300 - EH1200 combination kit (A520-10-140)
Qty Part Number Description Check ()
2 A20501052 Frame/base runner 
1 C10009111 ISO100-ISO63 adaptor 
1 B27158170 ISO63 trapped O-ring 
1 B27158171 ISO100 trapped O-ring 
12 C10007151 ISO63-ISO100 half claw for tapped holes 
4 218181452 M10 x 25 bolt 
4 218981311 M10 washer 
4 218983511 M10 s.coil washer 
1 A35202880 EH Mechanical Booster/ES Single Stage Rotary Pump
Combination Pumping Systems instruction manual

1 A35202840 ES EH Combination Kits instruction manual 
Table 6 - ES300 - EH2600/4200 combination kit (A520-10-150)
Qty Part Number Description Check ()
2 A22440100 Frame ends 
2 A22440101 Frame upper support channel 
2 A22440102 Frame base runner 
2 A22440103 Frame cross brace 
1 A22440124 Support cross piece 
1 B27158170 ISO63 trapped O-ring 
2 B27158171 ISO100 trapped O-ring 
12 C10007151 ISO63-ISO100 half claw 
4 C10007156 ISO63-ISO100 single claw clamp 
1 C10009120 ISO100-ISO63 stainless steel spacer 
1 C10009670 ISO100 bellows 
4 218181497 M12 x 50 hex head screw - stainless steel 
2 218181501 M12 x 70 hex head screw - stainless steel 
4 218181502 M12 x 80 hex head screw - stainless steel 
