Unpack and Inspect
A352-02-840 Issue A
Table 8 - ES630 - EH2600/4200 combination kit (A520-10-170)
Qty Part Number Description Check ()
2 A22440120 Frame ends 
2 A22440121 Frame upper support channel 
2 A22440122 Frame base runner 
2 A22440123 Frame cross brace 
1 A22440124 Support cross piece 
3 B27158171 ISO100 trapped O-ring 
16 C10007151 ISO63-ISO100 half claw clamp 
1 C10009125 ISO100 spacer stainless steel 
1 C10009670 ISO100 bellows 
4 218181497 M12 x 50 hex head screw - stainless steel 
2 218181501 M12 x 70 hex head screw - stainless steel 
4 218181502 M12 x 80 hex head screw - stainless steel 
8 218181564 M16 x 60 hex head screw - stainless steel 
4 218181566 M16 x 80 hex head screw - stainless steel 
4 218181658 M20 x 80 hex head screw - stainless steel 
4 218430160 M10 x 30 hex head socket grub screw 
4 218790011 M16 eye bolt 
4 218960911 M10 full nut stainless steel 
10 218960912 M12 full nut stainless steel 
4 218960916 M20 full nut stainless steel 
2 218981311 M10 plain washer 
20 218981312 M12 plain washer 
8 218981314 M16 plain washer 
8 218981316 M20 plain washer 
4 218983511 M10 spring coil washer 
10 218983512 M12 spring coil washer 
8 218983514 M16 spring coil washer 
4 218983516 M20 spring coil washer 
1 A35202880 EH Mechanical Booster/ES Single Stage Rotary Pump
Combination Pumping Systems instruction manual

1 A35202840 ES EH Combination Kits instruction manual 
