STP-L301/L451 Series Instruction Manual

13-4

turbomolecular pump

SERIAL NO:

MANUFACTURING DATE :

WEIGHT:

RATED SPEED :

rpm

MANUFACTURED BY:Edwards Japan Limited.

1078-1,Yoshihashi,Yachiyo-shi,Chiba,Japan

STP-

Figure 13.3 Label Affixing Position for the STP Pump
