STP-L301/L451 Series Instruction Manual

9-2

Operation

TUNING COMPLETE

RATING: 48000 rpm

LEVITATION

TUNING!

Tuning Complete

Tuning in Progress

PUMP TEMP: **

℃

Press RESET

switch for 3 sec.

< LCD Message ><STP Pump State> <Operation>

Levitation State

TEST COMPLETE

SELF TEST Execute Self Test

P021* ver.*.**

Breaker ON

Figure 9.1 Tuning Procedures
