STP-L301/L451 Series Instruction Manual

6-6

Installation

6.1.4 Side Panel (Left side)

(24) Air Cooling Fan

z For cooling the inside of the STP control unit.

(24)

Figure 6.4 STP Control Unit Side Panel (Left side)
