EET PMC-D726M - Setup Configuration Via the Front Panel; Making Setup Changes

CET Electric Technology
24
Display 3
P.F. Total
Frequency
Display 4~
Inc (Calculated Neutral)
Display 5~
COM (Communication Status)
Display 6
2
DI1
DI1 Status (OFF/ON)
Display 7
2
DI2
DI2 Status (OFF/ON)
Display 8
3
DO1
DO1 Status (OFF/ON)
Display 9
3
DO2*
DO2 Status (OFF/ON)
<Phase>
Display 1
Ia
Ib
Ic
Display 2
1
Uan
Ubn
Ucn
Display 3
Uab
Ubc
Uca
Display 4
1
kWa
kWb
kWc
Display 5
1
kvara
kvarb
kvarc
Display 6
1
kVAa
kVAb
kVAc
Display 7
1
P.F.a
P.F.b
P.F.c
<Energy>
Display 1
kWh Import
Display 2
kWh Export
Display 3
kvarh Import
Display 4
kvarh Export
Display 5
kVAh
Display 6~9
#
kWh Import of T1 to T4
Display 10~13
#
kWh Export of T1 to T4
Display 14~17
#
kvarh Import of T1 to T4
Display 18~21
#
kvarh Export of T1 to T4
* Available in Firmware V1.00.03 or later.
#
Available in Firmware V1.00.04 or later.
~ Available in Firmware V1.00.07 or later.
Table 3-5 PMC-D726M Data Display Screens
Notes:
1) This screen only appears when the Wiring Mode is set to Wye.
2) This screen only displays on Model with the DI options.
3) This screen only displays on Model with the DO options.
3.5 Setup Configuration via the Front Panel
Pressing the <Setup> button for more than 2 seconds enters the Setup Configuration mode where the
setup parameters can be changed. Upon completion, pressing the <Setup> button for more than 2
seconds returns to the Data Display mode.
3.5.1 Making Setup Changes
1) Entering the Password:
 Press the <Setup> button for more than 2 seconds to access Setup Configuration mode.
 Press the <Energy> button to advance to the Password page.
 A correct password must be entered before changes are allowed. The factory default password
is zero. Press the <Setup> button to select the parameter for modification. Use the <System>,
<Phase> and <Energy> buttons to enter the correct password.
2) Selecting a parameter to change:
 Use the <Phase> and <Energy> button to scroll to the desired parameter.
 Press the <Setup> button to select the parameter. Once selected, the parameter value will blink.
3) Changing and saving a parameter:
 Use the <System>, <Phase> and <Energy> buttons to make modification to the selected
parameter.
