EET PMC-D726M - Demands; Present Demands; Peak Demand Log of this Month (Since Last Reset); Peak Demand Log of Last Month (before Last Reset)

CET Electric Technology
40
1620
RO
Ubn (Wye)/Ubc (Delta) HD02
Float
1622
RO
Ucn (Wye)/Uca (Delta) HD02
Float
1624~1790
RO
…
Float
1792
RO
Uan (Wye)/Uab (Delta) HD31
Float
1794
RO
Ubn (Wye)/Ubc (Delta) HD31
Float
1796
RO
Ucn (Wye)/Uca (Delta) HD31
Float
Table 5-6 Voltage Harmonic Measurements
Notes:
1) When the Wiring Mode is Wye, the phase A/B/C Voltage THD/TOHD/TEHD/HDxx mean phase AB/BC/CA
Voltage THD/TOHD/TEHD/HDxx.
5.4 Demands
The Demand registers are available in Firmware Version V1.00.04 (LED)/V1.01.04 (LCD) or later.
5.4.1 Present Demands
Register
Property
Description
Format
Scale
Unit
3000
RO
Ia
INT32
x1000
A
3002
RO
Ib
INT32
3004
RO
Ic
INT32
3006
RO
kW Total
INT32
x1000
kW
3008
RO
kvar Total
INT32
x1000
kvar
3010
RO
kVA Total
INT32
x1000
kVA
Table 5-7 Present Demand Measurements
5.4.2 Peak Demand Log of This Month (Since Last Reset)
Register
Property
Description
Format
Scale
Unit
3400~3405
RO
Ia
See
Section 5.4.4
Demand Data
Structure
x1000
A
3406~3411
RO
Ib
3412~3417
RO
Ic
3418~3423
RO
kW Total
kW
3424~3429
RO
kvar Total
kvar
3430~3435
RO
kVA Total
kVA
Table 5-8 Peak Demand Log of This Month (Since Last Reset)
5.4.3 Peak Demand Log of Last Month (Before Last Reset)
Register
Property
Description
Format
Scale
Unit
3600~3605
RO
Ia
See
Section 5.4.5
Demand Data
Structure
x1000
A
3606~3611
RO
Ib
3612~3617
RO
Ic
3618~3623
RO
kW Total
kW
3624~3629
RO
kvar Total
kvar
3630~3635
RO
kVA Total
kVA
Table 5-9 Peak Demand Log of Last Month (Before Last Reset)
5.4.4 Demand Data Structure
Offset
Description
+0
High
Year - 2000
Low
Month
+1
High
Day
Low
Hour
+2
High
Minute
Low
Second
+3
-
Millisecond
+4~+5
-
Peak Demand Value
Table 5-10 Demand Data Structure
5.5 SOE Log
Each SOE event occupies 8 registers as shown in the following table. The SOE LOG Data Structure is
