45
6556
RW
Active Delay
UINT16
0 to 9999 s, 10*
6557
RW
Inactive Delay
UINT16
0 to 9999 s, 10*
6558
RW
Trigger Action 1
3
UINT16
0 to 4
6559
RW
Trigger Action 2
3
UINT16
Table 5-18 Setpoint Setup Parameters
Notes:
1) The PMC-D726M provides the following Setpoint parameters:
Key
Parameter
Scale/Unit
0
None
-
1
ULN
x100, V
2
ULL
x100, V
3
I
x1000, A
4
In
x1000, A
5
FREQ
x100, Hz
6
kW Total
x1000, kW
7
kvar Total
x1000, kvar
8
kVA Total
x1000, kVA
9
P.F. Total
x1000
10
kW Total Demand
x1000, kW
11
kvar Total Demand
x1000, kvar
12
kVA Total Demand
x1000, kVA
Table 5-19 Setpoint Parameters
2) For Over Setpoint, the Setpoint parameter must exceed the Over Limit to become active and go below the
Under Limit to become inactive.
For Under Setpoint, the Setpoint parameter must go below the Under Limit to become active and exceed the
Over Limit to become inactive.
3) The PMC-D726M provides the following Setpoint Triggers:
Key
Action
0
None
1
DO1 Closed
2
DO2 Closed
Table 5-20 Setpoint Triggers
5.7 TOU Setup
5.7.1 Basic
Register
Property
Description
Format
Range, Default*
7000
RO
Current Tariff
1
UINT16
0=T1, 1=T2, 2=T3, 3=T4
7001
RO
Current Season
UINT16
0 to 5
(Season #1 to #6)
7002
RO
Current Period
UINT16
0 to 5
(Period #1 to #6)
7003
RO
Current Daily Profile No.
UINT16
0 to 9
(Daily Profile #1 to #10)
7004
RO
Current Day Type
UINT16
0=Weekday1
1=Weekday2
2=Weekday3
3= Alternate Day
7005~7008
RW
Reserved
UINT16
7009
RW
Sunday Setup
UINT16
0=Weekday1*
1=Weekday2
2=Weekday3
7010
RO
Monday Setup
UINT16
7011
RO
Tuesday Setup
UINT16
7012
RO
Wednesday Setup
UINT16
7013
RO
Thursday Setup
UINT16
7014
RO
Friday Setup
UINT16
7015
RO
Saturday Setup
UINT16
Table 5-21 TOU Basic Setup
