Table 5-13 SOE Event Classification
5.6 Device Setup
5.6.1 Basic Setup Parameters
Register
Property
Description
Format
Range/Unit
6000
#
RW
PT Primary Voltage
#1
INT32
1V to 1,000,000V
4
None
Over In Setpoint Active
5
None
Over Frequency Setpoint Active
6
None
Over kW Total Setpoint Active
7
None
Over kvar Total Setpoint Active
8
None
Over kVA Total Setpoint Active
9
None
Over PF Total Setpoint Active
10
None
Over kW Total Present Demand Setpoint Active
11
None
Over kvar Total Present Demand Setpoint
Active
12
None
Over kVA Total Present Demand Setpoint
Active
13~60
None
Reserved
61
None
Under Uln Setpoint Active
62
None
Under Ull Setpoint Active
63
None
Under Current Setpoint Active
64
None
Under In Setpoint Active
65
None
Under Frequency Setpoint Active
66
None
Under kW Total Setpoint Active
67
None
Under kvar Total Setpoint Active
68
None
Under kVA Total Setpoint Active
69
None
Under PF Total Setpoint Active
70
None
Under kW Total Present Demand Setpoint
Active
71
None
Under kvar Total Present Demand Setpoint
Active
72
None
Under kVA Total Present Demand Setpoint
Active
129
None
Return
Value
Over Uln Setpoint Return
130
None
Over Ull Setpoint Return
131
None
Over Current Setpoint Return
132
None
Over In Setpoint Return
133
None
Over Frequency Setpoint Return
134
None
Over kW Total Setpoint Return
135
None
Over kvar Total Setpoint Return
136
None
Over kVA Total Setpoint Return
137
None
Over PF Total Setpoint Return
138
None
Over kW Total Present Demand Setpoint
Return
139
None
Over kvar Total Present Demand Setpoint
Return
140
None
Over kVA Total Present Demand Setpoint
Return
141~188
None
Reserved
189
None
Under Uln Setpoint Return
190
None
Under Ull Setpoint Return
191
None
Under Current Setpoint Return
192
None
Under In Setpoint Return
193
None
Under Frequency Setpoint Return
194
None
Under kW Total Setpoint Return
195
None
Under kvar Total Setpoint Return
196
None
Under kVA Total Setpoint Return
197
None
Under PF Total Setpoint Return
198
None
Under kW Total Present Demand Setpoint
Return
199
None
Under kvar Total Present Demand Setpoint
Return
200
None
Under kVA Total Present Demand Setpoint
Return
