CET Electric Technology
44
3
I avg
8
kWa
13
FREQ
4
Uab
9
kWb
Table 5-15 AO Key
In the table above, FREQ with a scale "×100, Hz", PF Total with a scale "×1000", the values of the other
parameters in the registers are in accordance with the actual values.
4) Voltage, Current Specification and corresponding Pulse Constant
Voltage Inputs
Current Inputs
Pulse Constant options (imp/kWh)
57.7VLN/100VLL
1A
1000/3200/5000/6400/12800
5A
1000/3200/5000/6400/12800
2.5mA
1000/3200/5000/6400/12800
40mA
40/100/400/1000
240VLN/415VLL
1A
1000/3200/5000/6400/12800
5A
1000/3200/5000
2.5mA
1000/3200/5000
40mA
40/100/400
Table 5-16 Pulse Constant options
5) If a SOE CLR is performed from the front panel or via communications, the SOE Pointer will be reset to zero
and then immediately incremented by one with a new ”Setup Changes via Front Panel” or “Setup Changes
via Communications” event.
6) Writing 0xFF00 to the Clear All Demand register to clear all Demand registers and logs, including Present
Demand, Peak Demand Log of This Month (Since Last Reset) and Last Month (Before Last Reset).
7) The Self-Read Time applies to the Peak Demand Log and supports the following three options:
A zero value means that the Self-Read will take place at 00:00 of the first day of each month.
A non-zero value means that the Self-Read will take place at a specific time and day based on the formula:
Self-Read Time = (Day x 100 + Hour) where 0 Hour23 and 1 ≤ Day 28. For example, the value 1512
means that the Self-Read will take place at 12:00pm on the 15th day of each month.
A 0xFFFF value means the automatic self-read operation is disabled and the log will be transferred
manually.
5.6.2 I/O Setup Parameters
The I/O setup parameters are available in Firmware V1.00.03 (LED)/V1.01.03 (LCD) or later for PMC-
D726M with the I/O option.
Register
Property
Description
Format
Range, Default*
6100
RW
DI1 Debounce
UINT16
1ms to 9999ms, 20*
6101
RW
DI2 Debounce
UINT16
1ms to 9999ms, 20*
6102~6105
RW
Reserved
6106
RW
DO1 Pulse Width
UINT16
0 to 6000 (x0.1s), 0 = Latch Mode
10*
6107
RW
DO2 Pulse Width
UINT16
Table 5-17 I/O Setup
5.6.3 Setpoints Setup
Register
Property
Description
Format
Range, Default*
6500
RW
Setpoint #1
Setpoint Type
UINT16
0=Disabled*
1=Over Setpoint
2=Under Setpoint
6501
RW
Parameters
1
UINT16
0 to 12
6502
RW
Over Limit
2
INT32
0*
6504
RW
Under Limit
2
INT32
0*
6506
RW
Active Delay
UINT16
0 to 9999 s, 10*
6507
RW
Inactive Delay
UINT16
0 to 9999 s, 10*
6508
RW
Trigger Action 1
3
UINT16
0 to 2
6509
RW
Trigger Action 2
3
UINT16
6550
RW
Setpoint #6
Setpoint Type
UINT16
0=Disabled*
1=Over Setpoint
2=Under Setpoint
6551
RW
Parameter
1
UINT16
0 to 12
6552
RW
Over Limit
2
INT32
0*
6554
RW
Under Limit
2
INT32
0*
