49
Day
9825
RO
Serial Number
UINT32
e.g. 1601030100 means the
100
th
PMC-D726M that was
manufactured on January 3
rd
,
2016
9827
RO
Reserved
UINT16
9828
RO
D726X Model
UINT16
3=D726M, Others=Reserved
9829
RO
Feature Number
Bitmap
B4B3B2B1B0:
0xx00=No DI/DO/AO
0xx01=2 DIs
0xx10=1 DO
0xx11=1 AO
1xx00=2 DIs+2 DOs
1xx01=2 DIs+2 Pulse Outputs
Bits 5 to 15: Reserved
9830
RO
Current Input
UINT16
1A / 5A
2
/ 40 mA~
9831
RO
Voltage Input
UINT16
120 / 415 (V)
*Default
~ Available in Firmware V1.00.07 (LED)/V1.01.07 (LCD) or later
Table 5-29 Meter Information
Notes:
1) The Meter Model appears from registers 9800-9819 and contains the ASCII encoding of the string “PMC-
D726M” as shown in the following table.
Register
Value(Hex)
ASCII
9800
0x50
P
9801
0x4D
M
9802
0x43
C
9803
0x2D
-
9804
0x44
D
9805
0x37
7
9806
0x32
2
9807
0x36
6
9808
0x4D
M
9809~9819
0x20
Null
Table 5-30 ASCII Encoding of “PMC-D726M”
2) For 2.5mA (SCCTA Option for 5A SCCT) Current Input, the Current Input would be read as 5A too.
