27Service Guide: EFI Fiery Central integrated server
Replacing parts
• All boards installed on the motherboard
• All cables connected to the motherboard (including the motherboard power cable, CPU power cable, front panel
fan cable, hard disk drive data cable, DVD drive power and data combination cable, power button cable, reset
button cable, speaker cable, front panel USB port cables, and UIB cable)
This section also includes information about the following:
• Replacing or adding DIMMs
• Replacing the CPU
• Replacing the battery
• Jumper configurations
Important: Follow standard ESD and other safety precautions when handling components (see page 8). During
service to the motherboard, avoid using excessive force and always place the motherboard on a grounded,
non-metallic, static-free surface. Never allow any metal to touch the solder contacts on the underside of the
motherboard, especially beneath the battery socket. Improper handling can short-circuit and permanently
damage the motherboard.
