79Service Guide: EFI Fiery Central integrated server
Servicing the Fiery Central integrated server with furniture
3 Remove the thumbscrews that attach the FC integrated server stability bracket to the stand.
4 Lift the bracket and gently pull the FC integrated server away from the table top.
Make sure to pull the FC integrated server out just enough so that the front panel of the FC integrated server is
aligned with the back edge of the table top.
1Thumbscrews
2 Stability bracket
