Electrostatic
discharge (ESD)
IEC 61000-4-2
+6 kV contact
+8 kV air
+2, 4, 6 kV
contact
+2, 4, 8 kV air
Floors should be wood,
concrete or ceramic tile. If
floors are covered with
synthetic material, the
relative humidity should be at
least 30 %.
Electrical fast
transients/bursts
IEC 61000-4-4
+2 kV for power
supply lines
+1 kV for
input/output lines
Not applicable
Not applicable
The test is applicable since
the EUT
does not have AC/DC power
ports and signal/
interconnecting cable
longer than 3m.
Surge
IEC 61000-4-5
+1 kV line(s) to
line(s)
+2 kV line(s) to
earth
Not applicable
Not applicable
The test is not applicable
since the EUT does not have
AC power port.
Voltage dips,
short
interruptions and
voltage
variations on
power supply
lines
IEC 61000-4-11
<5% UT
(>95% dip in UT)
for 0.5 cycle
40% UT
(60% dip in UT )
for 5 cycles
70% UT
(30% dip in UT )
for 25 cycles
<5% UT
(>95% dip in UT)
for 5 sec
Not applicable
Not applicable
Not applicable
Not applicable
The test is not applicable
since the EUT does not have
AC power port.
