PRODUCT DESCRIPTION
10/2022 11 NP-DK50 2V-A-4_10-2022-AD
The regulator must be selected according to the application to the filter set, or separately The
regulator shall ensure constant pressure at the outlet.
Regulator complete
(to the filter assembly)
Filter set brackets
A suitable bracket must be ordered for every filter set.
Equipotential bonding socket
The socket provides protective bonding.
8. PRODUCT FUNCTION
8.1. Compressor with adsorption dryer
(Fig. 1) The air pump (1) draws in air through the inlet filter (7) and supplies compressed air through
the connecting hose into the adsorption dryer (8). From the inlet to the dryer module, the air is first
cooled in the integrated cooler (26) and then moves through the condensate separator (32), entering
the active chamber with adsorbent (27), where the air is dried. A portion of the air is fed into the
second, regenerated chamber, where this air is used to remove moisture from the adsorbent, after
which it is vented to the atmosphere. The active chamber switches on a cyclical basis. The dry air
then passes through the non-return valve (3) into the air tank (2). Air drying efficiency (the pressure
dew point) is determined by the dew point sensor located in the air tank.
It is not necessary to drain the air tank.
8.2. Compressor in cabinet
(Fig. 3) The soundproof cabinet provides compact covering of the compressor, dampens noise
efficiently, providing sufficient exchange of cooling air. Its design makes it suitable for use in rooms
where low noise levels are required. The fan under the compressor pump provides cooling of the
compressor, it is in operation at the same time with compressor motor or after switching on the
temperature switch at temperature above 40 °C. After cooling the cabinet area approximately under
32°C, the fans turn off automatically.
The dryer display (34) is located on the front panel of the cabinet.
Compressor-mounted bracket
