11. PNEUMATIC CONNECTION
11.1. Connecting to the compressed air outlet
 Connect the pressure hose (2) to the compressed air outlet (1) of the compressor (Fig. 6).
 Secure the pressure hose in the clamp (3) (Fig. 6).
 Route the pressure hose through the opening on the left side in the back wall of the cabinet
(Fig. 8) on compressors in cabinet.
