USB Connector
Used to update and configure the D12 firmware.
Note: A Standard USB-A to USB-Mini-B cable must be utilized for firmware updates and is not included with the
D12.
USB Connection
AC Power Connector
A removable IEC compatible AC Power cord is included for connecting the AC Power Connector to 120VAC power.
REPLACE WITH
SAME TYPE AND
RATING ONLY.
120V 50/60 Hz
1440W
T12.5 AL
AC Power Connector
