D12 INSTALLATION MANUAL
Specifications
Audio Section
Output Power RMS 100WPC @ 4 Ohms, 75WPC @ 8 Ohms all channels driven
Frequency Response
20Hz to 20kHz -3 dB at 8 Ohms
Full Power Bandwidth
10Hz to 25kHz
Signal to Noise
> 102 dB (A weighted)
Channel Separation
> -70dB (channel to channel @ 1kHz)
Total Harmonic Distortion
< .04%
Intermodulation Distortion
< 0.1%
Input Impedance
49k Ohms
Connectors
Input/Loop Output
RCA Stereo
Speaker Output
Gold Plated 5 Way Binding Post
Power
AC Power Requirements
120VAC, 1440W / 240VAC, 1440W
Current Draw
12A @ 120 VAC / 6A @ 240VAC
Standby Power saving Mode
20W
Triggers
Remote Trigger Input
5 to 24 Volts AC/DC
Loop Output trigger
+12VDC @ 10 mA
Dimensions w/Feet (3U w/o Feet
In.
17 W x 5 7/8 H x 17 D
mm.
432 W x 149 H x 432 D
Weight
lbs.
47
kg.
21.32
Technical Support
If, after carefully following the steps in the Troubleshooting section, you are unable
to resolve issues with the installation or operation of the D12 Digital Power Amplifier,
please call ELAN Technical Support at 1-800-622-ELAN (3526).
