IR Control
Symptom Possible Cause Solution
IR Icon does NOT flash
when a button pressed.
1. IR controller not programmed.
2. IR signal path wiring bad.
Program IR controller.
Set D12 to ELAN mode
Verify IR signal path wiring.
Check keypads, IR sensors, IR
distribution blocks, D12 IR Input
jack, IR emitters, etc.
No channel selected
from IR controller.
IR Icon DOES flash when
button pressed.
1. Incorrect IR commands
programmed (not D12 commands).
2. Chassis codeset incorrect.
Verify/correct IR programming.
Verify/correct IR programming.
Intermittent or no control from
IR controller. IR Icon on LCD
flickers or is lit constantly.
IR flooding. Check IR receivers for ambient light or
plasma TV flooding.
Incorrect channel and/or chas-
sis selected.
Incorrect D12 IR commands
programmed.
Verify/correct IR programming.
