D12 INSTALLATION MANUAL
Stand-Alone Stereo Bussing with Multiple Chassis
Prerequisites First D12 Chassis
Factory defaulted
ELAN mode
Channel Range:
Set to 1 to 12
VIA!NET Address:
Set to 0
Input Select Menu:
Channel All ODD with Input set to 1 Bus A
Channel All Even with Input set to 2 Bus A
See:
"Restore Defaults" on page 20
"Operating Mode" on page 13
"Channel Range" on page 23
"VIA!NET Address" on page 23
"Input Select Menu" on page 8
Prerequisites Second D12 Chassis
Factory defaulted.
ELAN mode
Channel Range:
Set to 13 to 24
VIA!NET Address:
Set to 1
Input Select Menu:
Channel All ODD with Input set to 1 Bus A
Channel All Even with Input set to 2 Bus A
See:
"Restore Defaults" on page 20
"Operating Mode" on page 13
"Channel Range" on page 23
"VIA!NET Address" on page 23
"Input Select Menu" on page 8
This example shows the preamp output of an A/V Receiver being distributed in a wide-area application, such as a
great room. Speakers for both chassis are stereo for up to 12 pairs of speakers.
