D12 INSTALLATION MANUAL
ELAN special application
Prerequisites:
Factory defaulted
ELAN mode
Channel Range:
Set to 1 to 12
Input Select Menu:
Channel 1 with Input set to 1 Bus A
Channel 2 with Input set to 2 Bus A
Channel 3 with Input set to 1 Bus A
Channel 4 with Input set to 2 Bus A
See:
"Restore Defaults" on page 20
"Operating Mode" on page 13
"Channel Range" on page 23
"Input Select Menu" on page 8
Instead of using volume controls to have independent control of the volume in a zone and sub zone, control the
channels of the D12 using IR Commands. Route the FIX out of the S128P to audio input 1 and audio input 2 (Bus
A).
The S128P increases or decreases the volume level for channels 1 and 2 Main Zone.
To control the Sub Zone speakers that are connected to channel 3 and 4, send D12's IR Commands Channel 3
Volume Up, Channel 3 Volume Down, Channel 4 Volume Up and/or Channel 4 Volume Down to the D12.
These commands can be programmed on a different ELAN control located in the Sub Zone or from the same control
located in the Main Zone.
