ELAN HC6/HC12 INSTALLATION MANUAL
© ELAN 2010 | All rights reserved.
Page 1
Preface
Purpose of this Manual
This manual provides step-by-step installation instructions and connection examples, along with basic user information for
installation and ongoing use of the HC6/HC12 System Controller. This manual is written for the installer of this equipment.
Please see the Configurator Reference Guide and Integration Notes for programming information.
These can be found at www.elanhomesystems.com/dealer.
Organization
The following information is contained in this manual.
Safety Information
Provides a comprehensive list of safety practices and procedures allowing for the safe installation and
operation of ELAN’s HC6/HC12 System Controller.
HC6/HC12 Introduction
Provides an introduction to ELAN’s HC6/HC12 System Controller, along with system features to
include Front and Rear panel controls, indicators and connections, along with a short description of
each.
HC6/HC12 System Design
Provides a system design application overview of the HC6/HC12 System Controller.
HC6/HC12 Connections
Provides a description of the HC6/HC12 System Controller system connections and direct
connections from the HC6/HC12 to other components.
HC6/HC12 Operation
Provides location and function of switches and LEDs.
Precision Panels
Provides function and connection information for Precision Panels used in conjunction with the
HC6/HC12.
Troubleshooting
Provides troubleshooting tables to help fix common problems that may be encountered when
installing the HC6/HC12 System Controller.
Network Information
Appendix A provides information on IP setup and router port forwarding for the HC6/HC12 System
Controller.
Rack Mounting
Appendix B provides specifications for rack mounting the HC6/HC12 System Controller.
Specifications
Provides equipment specifications for the HC6/HC12 System Controller.
