4.2.3 Control panel configuration
The washing programmes, the functions of the selector knob and the various buttons vary according to the
model, since these are determined by the configuration of the appliance.
4.2.3.1 Programme selector (S1)
The knob has 15 non configurable positions.
There is no ON/OFF switch.
The 0 (zero) position is reserved for resetting the programme that is running
and turn off all the LEDs on the display board.
The plug must be removed from the mains socket to cut the power to the
appliance.
The various positions of the selector may be configured in order to perform the
various washing programmes (e.g. water level, drum movement, No. of rinses
and the washing temperature to be selected according to the type of laundry).
The selector can be turned both clockwise and anti-clockwise.
For each programme, the compatible options and other parameters are defined.
The programme temperature is selected using the relevant sensor.
4.2.3.2 Programme configuration
The table below lists the parameters that can be used to define the washing programmes.
Types of fabric
Cotton/linen, Synthetic fabrics, Delicates, Wool, Hand-wash,
Shoes, Jeans, Duvet, Silk.
Special programmes
Cotton/linen + pre-wash, Soak, Mini-programme, Easy-Iron,
Conditioner, Rinse, Drain, Spin, Economy.
Temperature
Normal, Minimum, Maximum: the initial temperature is the one
proposed for the washing programme.
Normal, Minimum, Maximum.
Options (Normal/Possible)
Rinse hold, Pre-wash, Extra rinse, Easy-Iron, Economy (energy
label), Normal, Super quick, Reduced spin speed, No spin.
Pre-wash, Wash, Rinses, Spin, Delayed start.
Technical Support - DMM 10/124 599 75 58-67 Rev.04
