22.2 Key to diagram
Appliance electrical components PCB components
2. Door safety interlock
3. Electronic pressure switch
4. NTC
5. Pre-wash solenoid valve
6. Wash solenoid valve
7. Universal motor
8. Tachometric (motor)
9. Stator (motor)
10. Rotor (motor)
11. Heating element
12. Display board
DRAIN_YTY Drain pump Triac
DOOR_TY Door interlock Triac
PWELT_TY Pre-wash solenoid Triac
WELV_TY Wash solenoid Triac
MOTOR_TY Motor Triac
K1 Heating element relay
K2 Heating element relay
K3 Motor relay: clockwise rotation
K4 Motor relay: anti-clockwise rotation
K5 Motor relay: half-field power supply
Technical Support - DMM 94/124 599 75 58-67 Rev. 03
