Electrolux EWM09311 - Alarm Codes E57-E6 A

Alarm
Code
Alarm Description Fault Condition Possible Fault Machine Action/Status Reset Key
E57 FCV Current trip
High current on inverter
(>15A)
Motor defective
Motor Wiring or Motor Control board defective
Cycle blocked after 5 trials
with door locked
ON/OFF
RESET
E58 FCV Over current
High current on motor
phase (>4.5A)
Motor defective, Motor Wiring or Motor Control board defective,
abnormal working condition
Cycle blocked after 5 trials
with door locked
ON/OFF
RESET
E59 FCV Not Following
No tacho signal from
tachometer for 3 seconds
Motor defective
Motor Wiring or Motor Control board defective
Cycle blocked after 5 trials
with door locked
ON/OFF
RESET
E5A FCV Heating
High temperature on Heat
Sink (>88°C) or NTC of
FCV board open
Over load condition, Motor Control board defective
Cycle blocked after 5 trials
with door locked
ON/OFF
RESET
E5H FCV Under Voltage
Dc bus voltage bellow the
allowed value (175V)
FCV mains wiring Motor Control board defective
Cycle blocked after 5 trials
with door locked
ON/OFF
RESET
E5C FCV Over Voltage
Dc bus voltage above the
allowed value (430V)
Motor Control board defective
Power line voltage too high
Cycle blocked after 5 trials
with door locked
ON/OFF
RESET
E5D FCV Unknown Message
Message received by FCV
is not correct
Transmission line noisy /
FCV defective
MB defective
Communication wiring problems
---
ON/OFF
RESET
E5E FCV-MB Communication
Protocol communication
between FCV and MB not
aligned
Wiring defective
FCV defective, WD defective,
UI defective
MB defective, Weight defective
Cycle blocked after 5 trials
ON/OFF
RESET
E5F FCV Fault
FCV control board is
continuously in reset
FCV control board defective or communication wiring problems
or main board defective
Cycle blocked after 5 trials
with door unlocked
ON/OFF
RESET
E61
Insufficient heating during
washing cycle
Washing heating timeout
expired
Washing NTC defective
Washing heater element defective
Wiring or main board defective
Heating phases skipped
START
RESET
E62
Overheating during washing
cycle
Water temperature higher
than 88°C for a time longer
than 5 minutes
Washing NTC defective
Wash heater element defective
Wiring or main board defective
Safety Drain cycle
Cycle stopped
with door unlocked
RESET
E66 Heater or drying relay failure
Incongruence between
heater relay sensing and
relay status
Main board defective
Current leakage between
Wash/drying heater element and earth
Safety load cycle.
Stop of the cycle
with door locked
ON/OFF
RESET
E68 Ground current leakage
Voltage value on heater
sensing (wash or dry)
different from Vmains value
Current leakage between
wash or dry heater element and earth
Cycle blocked with door
opened
START
RESET
E69
Washing heating
element opened
Voltage value different from
Vmains value when heating
element is not powered
during the cycle execution
Wash heating element faulty
(thermo fuses opened)
Wiring defective
Main board defective
No actions
START
ON/OFF
RESET
E6A Heating relay sensing failure
Wrong input signal to
microprocessor
Main board defective
Cycle blocked with door
locked
RESET
Technical Support - DMM 67/124 599 75 58-67 Rev. 04
