Electrolux EWM09311 - Alarm Codes ED6-EF5

Alarm
Code
Alarm Description Fault Condition Possible Fault Machine Action/Status Reset Key
ED6
WD thermostat
sensing failure
Signal of thermostat
sensing out of limits
WD board defective No actions
START
ON/OFF
RESET
ED7 WD thermostat failure
With satellite board:
Incongruence between WD
heating 1 and 2 relay
sensing or thermostat
sensing out of limits.
Without satellite:
Incongruence between
heater and drying relay
sensing.
Manual or automatic
thermostat opened,
wiring , WD board defective,
drying heater element,
No actions
START
ON/OFF
RESET
ED8
WD fan motor tachometer
absent
Bad or no signal from
tachometer
Fan Motor defective
Fan Motor Wiring or WD board defective
Skip drying phase
ON/OFF
RESET
ED9
WD fan motor driving circuit
alarm
Incongruence between fan
motor status and the
driving circuit sensing
signal
WD board defective Skip drying phase
ON/OFF
RESET
EDA
WD Power
Supply alarm
Power supply period
lower/higher than
configured values or power
supply values out of limits
Wrong or disturbed Power Supply line. WD board defective
Wait for nominal power supply
conditions
START
ON/OFF
RESET
EDB
(EDH)
WDM microcontroller fault
WDM microcontroller
damaged
WDM board defective
No actions to be performed. If
still present replace the WDM
Board
START
ON/OFF
RESET
EDC WDM heating element opened
Incongruence between
WDM heating 1 and 2 relay
sensing
Drying heating elements opened, unplugged, or wiring No actions
START
ON/OFF
RESET
EF1 Filter clogged warning
Difficulties to drain. Virtual
AB level remains in full
state after an established
time
Filter clogged or dirty
Drain pipe clogged/kinked/too high
Warning displayed at the end
of the cycle
START
RESET
EF2 Foam warning
Virtual AB level in full state
during spin phase at the
end of the washing phase
Excessive detergent dosing
Drain filter dirty or clogged
Drain pipe kinked or clogged
Alarm displayed after 5
attempts (if specific LED
configured)
RESET
EF3 Acqua Control warning
Acqua control sensing
signal high
(in appliance equipped with
safety device)
Water on the basement
Acqua Control defective
Drain pump activated
ON/OFF
RESET
EF4 Water load low pressure
Flow meter stooped with
electro valves switched on
Tap closed/low pressure of incoming water No actions RESET
EF5 Load too unbalanced
Final spin phase skipped
due to
a high unbalance load
Load unbalanced No actions
START
RESET
Technical Support - DMM 71/124 599 75 58-67 Rev. 04
