Section F - Ice Maker
Water
Ice Storage Bin
Water
Ice Storage Bin
C
o
n
t
r
o
l
A
r
m
Ejector
1. Ejector reaches ice.
2. Motor stalls until ice loosens.
3. Heater remains energized.
Harvest Cycle
Step 4
Step 5
1. Completing 1st revolution of
Ejector .
2. Water Fill Switch closes, but
heater remains on, preventing
water fill.
Harvest Cycle
Ice Storage Bin
C
o
n
t
r
o
l
A
r
m
Ice Storage Bin
Ejector
Ice
Step 6
1. End of 1st revolution.
2. Hold Switch opens.
3. Since Thermostat is still closed,
2nd revolution of Ejector begins.
Harvest Cycle
Ice Storage Bin
Ice Storage Bin
C
o
n
t
r
o
l
A
r
m
Ejector
Ice
Water
Ice Storage Bin
Water
Ice Storage Bin
C
o
n
t
r
o
l
A
r
m
Ejector
1. Holding Switch in normally open
position.
2. Heater remains energized.
3. Control Arm is rising.
Harvest Cycle
Step 3
