4 Section A - Installation
DOOR REMOVAL
1. Disconnect electrical supply.
2. Open both doors, then remove toe grille.
3. Close doors.
To Remove Refrigerator Door:
1. Remove two Hinge Cover screws.
Remove cover.
2. Trace around hinge with soft lead
pencil. This will make it easier to
realign doors when they are replaced.
3. Remove Top Hinge (Refrigerator).
4. Lift refrigerator door off bottom hinge
pin. Set door aside.
5. Remove bottom hinge, if necessary.
6. Reverse this procedure to reinstall
refrigerator door.
To Remove Freezer Door:
1. Disconnect water line that goes through lower hinge of
freezer door at connection located under front of freezer:
Grip water line firmly in one hand, then with 3/8" wrench or
fingers, push in on gray collar to release water connector.
NOTE
If installation requires the removal of the doors, trace around all hinges with a soft lead
pencil for easy relocation.
